Model Configuration / Configuration
| Model | Working Area (mm) | Laser Power (W) | Total Power (W) |
|---|---|---|---|
| DF-SL9060 | 900×600 | 80-130W | ≤3500W |
| DF-1212 | 1200×1000 | 80-130W | ≤3500W |
| DF-SL1610 | 1600×800 | 80-130W | ≤3500W |
| DF-SL1510 | 1800×800 | 80-130W | ≤3500W |
| DF-SL1512 | 1800×1000 | 80-130W | ≤3500W |
| DF-SL1514 | 1800×1200 | 130-150W | ≤3500W |
| DF-SL1816 | 1800×1400 | 130-150W | ≤3500W |
| DF-SL1818 | 1800×1600 | 150-180W | ≤3500W |
| DF-SL1820 | 1800×1800 | 150-180W | ≤3500W |
| DF-SL1827 | 1800×2500 | 150-180W | ≤3500W |
| DF-SL1832 | 1800×3000 | 150-180W | ≤3500W |
| DF-SL1920 | 1900×1800 | 150-180W | ≤3500W |
| DF-SL1927 | 1900×2500 | 150-180W | ≤3500W |
| DF-SL2016 | 2000×1400 | 150-300W | ≤3500W |
| DF-SL2020 | 2000×1800 | 150-300W | ≤3500W |
| DF-SL2022 | 2000×2000 | 150-300W | ≤3500W |
| DF-SL2027 | 2000×2500 | 150-300W | ≤3500W |
| DF-SL2030 | 2000×3000 | 150-300W | ≤3500W |
Custom non-standard specifications available (unit: mm)
Technical Parameters / Technical Parameter
| Positioning Accuracy | ±0.05mm |
| Transmission | Stepper Motor/Servo Motor |
| Supported Formats | DWG、DXF、JPG、AI、TIF、PLT、CDR、BMP、GIF |
| Cooling Method | Water Cooling |
| Working Voltage | 220V/110V，50/60Hz |
| File Transfer | USBUSB Cable to PC、USB drive、Network Cable |
Equipment Advantages / Equipment Advantage
| automatic feeding platform | faster and more convenient for flexible fabric processing。 |
| wide application | suitable for mass production in large and medium enterprises，also meets the needs of small enterprises and individual processing。 |
| real-time adjustment | operationSpeed、laser energy can be adjusted in real time，greatly satisfies customer operation。 |
| automatic energy compensation | laser energy automatic compensation function，cuttingthe effect is greatly improved。 |
| true-color TFT screen | the panel can displaytrue-colorprocessing pattern，and accurately know the processing coordinates of the laser head。 |
Frequently Asked Questions
01What kind of warranty and long-term support do you offer?
Every Dingfeng machine is covered by a 12-month warranty plus lifetime maintenance support. If a fault occurs during the warranty period, we supply the replacement parts; after the warranty we continue to provide spare parts and technical support at cost price.
02How long does production and delivery take?
For standard models, production usually takes 7 to 15 days after the deposit is received. For customized configurations or special voltage requirements, allow around 20 days. The exact date is written into the contract.
03How is the machine packed and shipped?
Every machine is packed in an export-grade wooden case with moisture-proof and shock-proof protection inside, suitable for long-distance sea freight. We send you photos of the packing and container loading, together with the shipping documents.
04Do you provide installation, training and after-sales service?
Yes. Each machine is delivered with an English manual and video guides, and our engineers support you online during installation and commissioning. When necessary, our after-sales engineers can travel to your factory to help with installation and training. Spare parts and technical support are available for the life of the machine.
05How can I get a quotation?
Tell us your material, working width, required output and destination port. Our sales team will recommend a suitable configuration and send you a quotation.
06How does automatic feeding work?
The machine feeds fabric from the roll continuously, so long runs are processed without manual loading between pieces.
07What roll size can it handle?
Working width and roll diameter are selected according to your fabric. Send us your roll dimensions and daily output.
08Can it combine with the vision system?
Yes – auto-feeding and vision recognition can work together for printed fabrics.
09What daily output can it achieve?
Output depends on the cutting pattern and speed. Tell us your target daily output and we will confirm the required power and feeding configuration.
