Product Parameters / Product Parameters
| No. | Diameter(mm) | Width(mm) | Voltage | Power(kw) | Speed(m/h) | Machine size(mm) | Packing size(mm) | Weight(kg) |
|---|---|---|---|---|---|---|---|---|
| 1 | 270 | 2000 | 220V/380V | 13 | 90-110 | 3400×2650×1350 | 2700×830×1600 | 900 |
| 2 | 320 | 1800 | 220V/380V | 15 | 100-135 | 4850×2620×1600 | 2700×410×1750 | 1200 |
| 3 | 320 | 2000 | 220V/380V | 15 | 110 | 4850×2820×1600 | 2900×1050×1750 | 1400 |
| 4 | 420 | 1800 | 220V/380V | 19 | 156 | 4850×2580×1600 | 2700×1050×1750 | 1500 |
| 5 | 420 | 2000 | 220V/380V | 28 | 156 | 4850×2780×1600 | 2900×1100×1750 | 1600 |
| 6 | 420 | 3300 | 220V/380V | 32 | 156 | 4050×3050×1750 | 4250×1280×1850 | 3200 |
| 7 | 610 | 1300 | 220V/380V | 45 | 280 | 3950×2100×1850 | 2250×1250×2000 | 1600 |
| 8 | 610 | 1800 | 220V/380V | 45 | 280 | 4950×2600×1850 | 2750×1240×2000 | 2000 |
| 9 | 610 | 2000 | 220V/380V | 45 | 280 | 4950×2800×1850 | 2900×1240×2000 | 2200 |
| 10 | 800 | 1800 | 220V/380V | 68 | 616 | 4950×2650×1980 | 2800×1450×2200 | 3100 |
| 11 | 800 | 2000 | 220V/380V | 68 | 616 | 4950×2850×1980 | 3000×1450×2200 | 3300 |
Frequently Asked Questions
01What kind of warranty and long-term support do you offer?
Every Dingfeng machine is covered by a 12-month warranty plus lifetime maintenance support. If a fault occurs during the warranty period, we supply the replacement parts; after the warranty we continue to provide spare parts and technical support at cost price.
02How long does production and delivery take?
For standard models, production usually takes 7 to 15 days after the deposit is received. For customized configurations or special voltage requirements, allow around 20 days. The exact date is written into the contract.
03How is the machine packed and shipped?
Every machine is packed in an export-grade wooden case with moisture-proof and shock-proof protection inside, suitable for long-distance sea freight. We send you photos of the packing and container loading, together with the shipping documents.
04Do you provide installation, training and after-sales service?
Yes. Each machine is delivered with an English manual and video guides, and our engineers support you online during installation and commissioning. When necessary, our after-sales engineers can travel to your factory to help with installation and training. Spare parts and technical support are available for the life of the machine.
05How can I get a quotation?
Tell us your material, working width, required output and destination port. Our sales team will recommend a suitable configuration and send you a quotation.
06What is different in the high-end version?
It is a higher configuration for industrial production, with more stable output on fabric, garments, ribbons and webbing.
07What materials can it handle?
Polyester fabrics, garments, ribbons and webbing.
08What working width is available?
Send us your maximum width and output target and we will confirm.
09What consumables and spare parts are needed?
Transfer paper is the main consumable. Silicone rollers and pads are available as spare parts.
