Model Configuration / Configuration
| Model | DF-980 50W | DF-980 45W | DF-980 80W |
|---|---|---|---|
| Laser Type | CO₂ Laser tube | Metal RF laser | Metal RF laser |
| Laser Power | 50W | 45W | 80W |
| Machine accuracy | ±0.2 | ±0.5 | ±0.5 |
| Max cutting width | 800mm | 800mm | 800mm |
| Max cutting thickness | ≤1.5mm | ≤2.2mm | ≤3mm |
| Motor type | Stepper MotorMotor | Servo Motor | Servo Motor |
Applicable Materials / Applicable Materials
adhesive vinyl、polyester film、kraft paper、cardboard、insulating paper、release paper、non-woven fabric、oxford fabric、leather、high-strength reflective film、non-metallic soft materials。
Applicable Industries / Applicable Industry
advertising production、LogoLogo、garment pattern making、outdoor wall advertising、banner industry、equipment coding、gift making, etc.。
Frequently Asked Questions
01What kind of warranty and long-term support do you offer?
Every Dingfeng machine is covered by a 12-month warranty plus lifetime maintenance support. If a fault occurs during the warranty period, we supply the replacement parts; after the warranty we continue to provide spare parts and technical support at cost price.
02How long does production and delivery take?
For standard models, production usually takes 7 to 15 days after the deposit is received. For customized configurations or special voltage requirements, allow around 20 days. The exact date is written into the contract.
03How is the machine packed and shipped?
Every machine is packed in an export-grade wooden case with moisture-proof and shock-proof protection inside, suitable for long-distance sea freight. We send you photos of the packing and container loading, together with the shipping documents.
04Do you provide installation, training and after-sales service?
Yes. Each machine is delivered with an English manual and video guides, and our engineers support you online during installation and commissioning. When necessary, our after-sales engineers can travel to your factory to help with installation and training. Spare parts and technical support are available for the life of the machine.
05How can I get a quotation?
Tell us your material, working width, required output and destination port. Our sales team will recommend a suitable configuration and send you a quotation.
06What is this machine used for?
Cutting laser film, vinyl and other flexible sheet materials with a waste removal system, so the finished sheet is clean.
07Does it need a special blade or cutter?
It is a plotter-style cutting machine with waste removal. Tell us your material and thickness and we will confirm the configuration.
08Can it cut pre-printed film?
Yes – film and vinyl are the typical materials for this machine.
