Product Parameters / Product Parameters
| Specification (CM) | Voltage (V) | Power (KW) | Time range (seconds) | Temperature range (℃) | Working pressure (KG/CM²) |
|---|---|---|---|---|---|
| 38×38 | 220/110 | 2.2 | 0-999 | 0-399 | 0-8 |
| 40×50 | 220/110 | 3.5 | 0-999 | 0-399 | 0-8 |
| 40×60 | 220/110 | 3.8 | 0-999 | 0-399 | 0-8 |
| 60×80 | 220/380 | 5 | 0-999 | 0-399 | 0-8 |
Product features / Product Characteristics
| PLC programming，with piece-counting function | PLC programmable control，with piece-counting function，supports manual mode / jog mode / fully automatic three operation modes，flexible and convenient operation。 |
| powerful cylinder | powerful cylinder，stable pressure，no air leakage，ensures consistent and stable pressing results。 |
| V -type worktable | Worktable with V -type base，double-sided printing，multi-purpose machine。 |
| automatic sensor switch | sensor probe should be aligned with the screw head 2MM within，heating plate will not press down automatically beyond the range，safe and reliable。 |
| Pressure 0-8KG Adjustable | Pressure 0-8KG Adjustable，adjustable for different materialsPressure，meets diverse process needs。 |
Frequently Asked Questions
01What kind of warranty and long-term support do you offer?
Every Dingfeng machine is covered by a 12-month warranty plus lifetime maintenance support. If a fault occurs during the warranty period, we supply the replacement parts; after the warranty we continue to provide spare parts and technical support at cost price.
02How long does production and delivery take?
For standard models, production usually takes 7 to 15 days after the deposit is received. For customized configurations or special voltage requirements, allow around 20 days. The exact date is written into the contract.
03How is the machine packed and shipped?
Every machine is packed in an export-grade wooden case with moisture-proof and shock-proof protection inside, suitable for long-distance sea freight. We send you photos of the packing and container loading, together with the shipping documents.
04Do you provide installation, training and after-sales service?
Yes. Each machine is delivered with an English manual and video guides, and our engineers support you online during installation and commissioning. When necessary, our after-sales engineers can travel to your factory to help with installation and training. Spare parts and technical support are available for the life of the machine.
05How can I get a quotation?
Tell us your material, working width, required output and destination port. Our sales team will recommend a suitable configuration and send you a quotation.
06What does automatic pneumatic mean?
The press closes by air pressure instead of a manual lever, so every cycle has the same pressure.
07Why the up-sliding design?
The machine slides along the rail so operators load and unload with less effort and shorter cycle time.
08What materials can it press?
Sublimation, DTF, vinyl and heat transfer applications on garments and flat items.
09Does it need an air compressor?
Yes – a pneumatic press needs a compressed air supply. Tell us your workshop setup and we will advise on the requirement.
