Model Configuration / Configuration
| Model | Working Area (mm) | Laser Power (W) | Total Power (W) | Cutting/Engraving Speed |
|---|---|---|---|---|
| DF-D1916 | 1750×1550 | 100-150W | ≤3500W | ≤7000 mm/s |
| DF-D1918 | 1750×1750 | 100-150W | ≤3500W | ≤7000 mm/s |
| DF-D1827 | 1600×2700 | 100-150W | ≤3500W | ≤7000 mm/s |
| DF-D1816 | 1650×1550 | 100-150W | ≤3500W | ≤7000 mm/s |
| DF-D1612 | 1450×1100 | 100-150W | ≤3500W | ≤7000 mm/s |
Custom non-standard specifications available (unit: mm)
Technical Parameters / Technical Parameter
| Camera | Industrial Camera (Industrial Camera) |
| Laser Type | CO2 CO₂ |
| Positioning Accuracy | ±0.05mm |
| Transmission | Stepper Motor/Servo Motor (Stepper/Servo Motor) |
| Supported Formats | DWG、DXF、JPG、AI、TIF、PLT、CDR、BMP、GIF |
| Cooling Method | Water Cooling (Water Cooling) |
| Operating Humidity | 5% – 95% |
| Operating Temperature | 0℃ – 45℃ |
| Working Voltage | 220V / 110V，50/60Hz |
| File Transfer | USBUSB Cable to PC、USB drive、Network Cable |
Applicable Industries / Applicable Industry
widely used for Muslim headscarves、scarves、flying cutting of garments、fabric/leather punching and engraving、full/half cutting of films、jeans burnout、marking various materials。
Frequently Asked Questions
01What kind of warranty and long-term support do you offer?
Every Dingfeng machine is covered by a 12-month warranty plus lifetime maintenance support. If a fault occurs during the warranty period, we supply the replacement parts; after the warranty we continue to provide spare parts and technical support at cost price.
02How long does production and delivery take?
For standard models, production usually takes 7 to 15 days after the deposit is received. For customized configurations or special voltage requirements, allow around 20 days. The exact date is written into the contract.
03How is the machine packed and shipped?
Every machine is packed in an export-grade wooden case with moisture-proof and shock-proof protection inside, suitable for long-distance sea freight. We send you photos of the packing and container loading, together with the shipping documents.
04Do you provide installation, training and after-sales service?
Yes. Each machine is delivered with an English manual and video guides, and our engineers support you online during installation and commissioning. When necessary, our after-sales engineers can travel to your factory to help with installation and training. Spare parts and technical support are available for the life of the machine.
05How can I get a quotation?
Tell us your material, working width, required output and destination port. Our sales team will recommend a suitable configuration and send you a quotation.
06What materials can it mark?
Wood, acrylic, leather, glass, plastics, rubber and coated metal surfaces.
07Why choose galvo instead of a static machine?
The galvo head marks at high speed, which suits production lines and higher marking volumes.
08What can it mark?
Serial numbers, logos, QR codes, barcodes and decorative patterns.
09Can it be integrated into a production line?
Yes – the marking software supports common file formats. Tell us your line setup and we will confirm the integration.
