Model Configuration / Configuration
| Model | Working Area (mm) | Laser Power (W) | Total Power (W) | Cutting/Engraving Speed |
|---|---|---|---|---|
| DF-PT6040 | 600×400 | 80W | ≤3500W | 0-600 / 0-1500 mm/s |
| DF-PT9060 | 900×600 | 80-150W | ≤3500W | 0-600 / 0-1500 mm/s |
| DF-PT1080 | 1000×800 | 80-150W | ≤3500W | 0-600 / 0-1500 mm/s |
| DF-PT1310 | 1300×1000 | 80-150W | ≤3500W | 0-600 / 0-1500 mm/s |
| DF-PT1390 | 1300×900 | 80-150W | ≤3500W | 0-600 / 0-1500 mm/s |
| DF-PT1490 | 1400×900 | 80-150W | ≤3500W | 0-600 / 0-1500 mm/s |
| DF-PT1610 | 1600×1000 | 80-150W | ≤3500W | 0-600 / 0-1500 mm/s |
| DF-PT1810 | 1800×1000 | 80-150W | ≤6000W | 0-600 / 0-1500 mm/s |
| DF-PT1910 | 1900×1000 | 130-150W | ≤6000W | 0-600 / 0-1500 mm/s |
Custom non-standard specifications available (unit: mm)
Technical Parameters / Technical Parameter
| CameraBrand | Canon (Canon) |
| Laser Type | CO2 CO₂ |
| Positioning Accuracy | ±0.05mm |
| Transmission | Stepper Motor/Servo Motor (Stepper/Servo Motor) |
| Supported Formats | DWG、DXF、JPG、AI、TIF、PLT、CDR、BMP、GIF |
| Cooling Method | Water Cooling (Water Cooling) |
| Operating Humidity | 5% – 95% |
| Operating Temperature | 0℃ – 45℃ |
| Working Voltage | 220V / 110V，50/60Hz |
| File Transfer | USBUSB Cable to PC、USB drive、Network Cable |
Applicable Industries / Applicable Industry
widely used in garments, shoe materials, home Textile、Handbags、Bags、Car Seat Covers、leather、Toysand other industries；stone、decorations、acrylic surface engraving、bamboo and wood crafts、paper、cartons、cigarette boxes, etc.
Frequently Asked Questions
01What kind of warranty and long-term support do you offer?
Every Dingfeng machine is covered by a 12-month warranty plus lifetime maintenance support. If a fault occurs during the warranty period, we supply the replacement parts; after the warranty we continue to provide spare parts and technical support at cost price.
02How long does production and delivery take?
For standard models, production usually takes 7 to 15 days after the deposit is received. For customized configurations or special voltage requirements, allow around 20 days. The exact date is written into the contract.
03How is the machine packed and shipped?
Every machine is packed in an export-grade wooden case with moisture-proof and shock-proof protection inside, suitable for long-distance sea freight. We send you photos of the packing and container loading, together with the shipping documents.
04Do you provide installation, training and after-sales service?
Yes. Each machine is delivered with an English manual and video guides, and our engineers support you online during installation and commissioning. When necessary, our after-sales engineers can travel to your factory to help with installation and training. Spare parts and technical support are available for the life of the machine.
05How can I get a quotation?
Tell us your material, working width, required output and destination port. Our sales team will recommend a suitable configuration and send you a quotation.
06What materials can it cut?
Cotton, silk, nylon, polyester, felt, fleece, non-woven and similar fabrics.
07Is the standard model suitable for start-up production?
Yes. It is designed for everyday cutting at a lower investment than the high-speed and vision models.
08Can it cut technical textiles or coated fabric?
Many technical textiles and coated fabrics can be cut. Tell us the material and thickness and we will confirm.
09What working area is available?
Several working areas are available. Tell us your maximum fabric width and we will recommend the suitable size.
